Vpro Optical Zoom Solid Microscope Vpro SM (0645 Series)

  • Porduct feature
  • Technical Scope
    • Product Name
      Vpro Optical Zoom Solid Microscope Vpro SM (0645 Series)
    • Product Model
      Vpro SM (0645 Series)
    • Characteristic

      Vpro SM (0645 Series) --- Instrument system specification

      Models SM0645( ) SM0645( ) SM1065( ) SM1065( )

      Total scale (standard) 6.5 to 45 times (T: freeze frame design)

      10 to 65 times (T: freeze design)

      Contact lens was 0.65 to 4.5 times (6.9: 1) 1.0 to 6.5 times (6.5: 1)

      Eyepiece 10 times (standard) / 15 times / 20 times / 30 times

      Optical design confocal, total center

      Vision 33. 8 ~ 4.9 mm 23 ~ 3.5 mm

      Optical body two-eye / 360 ∘ rotation three-eye /

      360 ∘ rotation two-eye / 360 ∘ rotation three-type / 360 ∘ rotation

      Image output - Yes - Yes

      Focal length 103 mm

      Pupil distance 52 ~ 75mm

      Diopter adjustment ± 7.5 D (designed on the mirror tube,

      independent adjustment; avoid dizziness)

      Ergonomic operator is not easy to fatigue and backache

      Center depth 125 mm

      Instrument weight 4.9 Kg 5.6 Kg 5.1 Kg 5.8Kg

    • Accessories
      test1
    • Notations
      test2

  • Vpro SM (0645 Series)

    project
    Auxiliary mirror
    Focal length
    eyepiece
    10 Times
    15 Times
    20 Times
    gain
    Vision (mm)
    gain
    Vision (mm)
    gain
    Vision (mm)
    parameter
    0.5 Times
    163 mm
    3.3 ~ 22.5
    67.7 ~ 9.8
    4.9 ~ 33.8
    49 ~ 2.7
    6.5 ~ 45
    40 ~ 5.8
    0.75 Times
    117 mm
    4.9 ~ 33.8
    45.1 ~ 6.5
    7.3 ~ 50.6
    32.8 ~ 4.7
    9.75 ~ 67.5
    26.6 ~ 3.8
    1.0 Times
    103 mm
    6.5 ~ 45
    33.8 ~ 4.9
    9.8 ~ 67.5
    24.6 ~ 3.5
    13 ~ 90
    20 ~ 2.9
    1.5 Times
    45 mm
    9.8 ~ 67.5
    22.5 ~ 3.3
    14.6 ~101.3
    16.4 ~ 2.3
    19.5 ~ 135
    13.3 ~ 1.9
    2.0 Times
    40 mm
    13 ~ 90
    16.9 ~ 2.5
    19.5 ~ 135
    12.3 ~ 1.8
    26 ~ 180
    10 ~ 1.4

    Vpro SM (1065 Series)

    project
    Auxiliary mirror
    Focal length
    eyepiece
    10 Times
    15 Times
    20 Times
    gain
    Vision (mm)
    gain
    Vision (mm)
    gain
    Vision (mm)
    parameter
    0.5 Times
    163 mm
    5 ~ 32.5
    46 ~ 7.4
    7.5  ~ 48.8
    32 ~ 5.0
    6.5 ~ 45
    40 ~ 5.8
    0.75 Times
    117 mm
    7.5 ~ 48.8
    30.7 ~ 4.7
    11.3 ~73.1
    21.3 ~ 3.3
    9.75 ~ 67.5
    26.6 ~ 3.8
    1.0 Times
    103 mm
    10 ~ 65
    23 ~ 3.5
    15 ~ 97.5
    16 ~ 2.5
    13 ~ 90
    20 ~ 2.9
    1.5 Times
    45 mm
    15 ~ 97.5
    15.3 ~ 2.4
    22.5 ~ 146
    10.7 ~ 1.6
    19.5 ~ 135
    13.3 ~ 1.9
    2.0 Times
    40 mm
    20 ~ 130
    11.5 ~ 1.8
    30 ~ 195
    8 ~ 12
    40 ~ 260
    6.5 ~ 1.0
