Design concept
● The machine is lightweight, easy to operate, easy to carry, high
precision multi-purpose quality control test.
● Peak (Peak) and instantaneous value (Track) conversion, as long
as the set button can be turned quickly and accurately.
● With AK (Kgf dial), AN (N dial), NK (Kgf and N double dial) three.
Instrument features
● High resolution value : Full model 1/200 scale board is clear and
easy to read.
● High precision: Full scale range 0.5 % (Full Scale)。
● Good operability : Rotation set button, peak and instantaneous
value read, easy.
● Model selection : The range is from 1 Kgf (10N) to 50 Kgf (500N).
● With the machine more accurate : Installed on the machine test
value is stable, high reproducibility, quality more reliable.
AKseries
|
Model
|
Maximum test range
|
Minimum scale
|
|
AK-1
|
1kgf
|
5gf
|
|
AK-2
|
2kgf
|
10gf
|
|
AK-3
|
3kgf
|
20gf
|
|
AK-5
|
5kgf
|
25gf
|
|
AK-10
|
10kgf
|
50gf
|
|
AK-20
|
20kgf
|
100gf
|
|
AK-30
|
30kgf
|
200gf
|
|
AK-50
|
50kgf
|
250gf
|
ANseries
|
Model
|
Maximum test range
|
Minimum scale
|
|
AN-10
|
10N
|
0.05N
|
|
AN-20
|
20N
|
0.1N
|
|
AN-30
|
30N
|
0.2N
|
|
AN-50
|
50N
|
0.25N
|
|
AN-100
|
100N
|
0.5N
|
|
AN-200
|
200N
|
1.0Nf
|
|
AN-300
|
300N
|
2.0Nf
|
|
AN-500
|
500N
|
2.5N
|
NKseries
|
Model
|
Maximum test range
|
Minimum scale
|
||
|
NK-10
|
10N
|
1kgf
|
0.05N
|
5gf
|
|
NK-20
|
20N
|
2kgf
|
0.1N
|
10gf
|
|
NK-30
|
30N
|
3kgf
|
0.2N
|
20gf
|
|
NK-50
|
50N
|
5kgf
|
0.25N
|
25gf
|
|
NK-100
|
100N
|
10kgf
|
0.5N
|
50gf
|
|
NK-200
|
200N
|
20kgf
|
1.0N
|
100gf
|
|
NK-300
|
300N
|
30kgf
|
2.0N
|
200gf
|
|
NK-500
|
500N
|
50kgf
|
2.5N
|
250gf
|
